Automatic IV Bag Spike Ports and Injection Ports Assembly Machine with PLC Control System and Stainless Steel Construction for 8000-15000pcs/hr Production

बड़ी छवि : Automatic IV Bag Spike Ports and Injection Ports Assembly Machine with PLC Control System and Stainless Steel Construction for 8000-15000pcs/hr Production

उत्पाद विवरण:

उत्पत्ति के प्लेस:	चीन
ब्रांड नाम:	SENCAN
प्रमाणन:	CE, ISO9001
मॉडल संख्या:	एससी-टीपी -739

भुगतान & नौवहन नियमों:

न्यूनतम आदेश मात्रा:	1 सेट
मूल्य:	Negotiate price according to actual situation
पैकेजिंग विवरण:	लकड़ी का केस
प्रसव के समय:	90 दिन
भुगतान शर्तें:	टी/टी, एल/सी
आपूर्ति की क्षमता:	2-20 सेट

संपर्क करें

विस्तृत उत्पाद विवरण

ऑपरेशन मोड:	स्वचालित	वारंटी अवधि:	1 वर्ष
इनफेड प्रकार:	कंपन डिस्क	नियंत्रण:	पीएलसी
उत्पाद आवृत्ति:	50 हर्ट्ज	केबल का आकार:	तीन-चरण पांच-तार प्रणाली
उत्पाद क्षमता:	4000-12000 कैप प्रति घंटे	प्रचालन पद्धति:	टर्नटेबल/यांत्रिक
ऑपरेशन प्रकार:	सूचकांक	ऑपरेशन टायर:	टर्नटेबल
प्रमुखता देना:	8000-15000pcs/hr IV Bag Spike Ports Assembly Machine , PLC Control System Injection Ports Assembly Machine , Stainless Steel Construction Medical Product Assembly Machine

IV Bag Spike Ports and Injection Ports Assembly Machine

Product Overview

Automated assembly system designed for spike ports and injection ports of non-PVC double tube soft bags, aluminum-plastic PC infusion ports, and PP/polypropylene dosing plugs.

Key Features

Constructed with stainless steel and aluminum alloy materials, compliant with ISO and GMP pharmaceutical packaging standards
Titanium alloy aluminum plastic cap sealing material with mirror-polished surface for superior sealing quality
Gear-driven rotation sealing knife system with individual cap sealing for high qualification rates
Integrated detection systems at each workstation ensuring assembly accuracy and correctness
Servo motor + indexing drive main power system for high-precision assembly operations
PLC control system with touch screen HMI for intuitive operation

Technical Specifications

Applicable Products	Aluminum-plastic caps & ports, PC ports, spike ports and injection ports for non-PVC soft tube IV bags
Production Speed	8,000 - 15,000 pcs/hr (customizable to customer requirements)
Qualified Product Rate	Above 99%
Operation Rate	Above 95%
Power Source	AC380V, 50Hz, 4kW/hr
Dimensions	L3500 × W3400 × H1800 (mm) (actual size varies with production speed)
Weight	Approximately 3000kg
Operator Requirement	1 person per machine
