उत्पाद विवरण:
भुगतान & नौवहन नियमों:
|
| संचालन विधा: | स्वत: | आकार: | अनुकूलन |
|---|---|---|---|
| उत्पाद प्रमाणन: | सीई, आईएसओ | आवेदन: | दैनिक आवश्यकताओं का उत्पादन |
| बिजली की आपूर्ति: | 220V/380V | प्रचालन दर: | 98% |
| वोल्टेज: | 220V | संचालन: | टच स्क्रीन |
| ऑपरेशन मोड: | टच स्क्रीन | प्रचालन इंटरफ़ेस: | टच स्क्रीन |
| फ़ायदा: | दोनों आकार एक साथ इकट्ठा किया जा सकता है | संरक्षा विशेषताएं: | आपातकालीन स्टॉप बटन, सुरक्षा सेंसर |
| मुख्य सामग्री: | स्टेनलेस स्टील | संतोषजनक दर: | लगभग 99% |
| ऑपरेटिंग सिस्टम: | स्वीकृति | ||
| प्रमुखता देना: | 100% Inspection Jelly Cap Assembly Machine,Emergency Stop Button Laundry Detergent Cap Screwing Machine,Safety Sensors Daily Necessities Assembly Machine |
||
Features
1. Customize rotary or loop type machine for customer’s capacity requirements.
2. Main power from servo motor + reducer unit, which provide intermittent motion and fixtures are in a static during assembling, high accuracy and qualified rate can be achieved.
3. Screw in place precisely, no twist angle and twist broken occur.
4. Does not destroy appearance of product, high qualified rate performed.
5. Option screw force detector for torque requirements.
6. Detection after each assembly process, 100% real qualified products.
7. All part made of stainless steel or aluminum alloy, in accordance with GMP requirements.
8. PLC control system, touch screen HMI operation.
9. Simple maintenance easy operation. No high technical requirement for Operator.
10. Easy maintenance of spare parts, short time replacement.
Properties
|
Applicable products |
Parts require scew fasten assembling |
|
Production speed |
2500-10000pcs/hr (according to customer’s requirement) |
|
Rate of qualified product |
Above 98%(depend on semi-product quality) |
|
Rate of operation rate |
Above 95% |
|
Power source |
AC380V, 50Hz, 3kw/hr |
|
Dimension |
Varied with different product and output |
|
Weight |
About 1500kg |
|
Operator |
1set/person |
