उत्पाद विवरण:
भुगतान & नौवहन नियमों:
|
| पैकेजिंग प्रकार: | लकड़ी का केस | तंत्र: | इमदादी |
|---|---|---|---|
| उत्पादन क्षमता: | 98% | प्रचालन प्रकार: | टूरटेबल/मैकेनिकल |
| स्वचालन ग्रेड: | स्वत: | हवा का दबाव: | 7kg/m3 |
| आवेदन: | चिकित्सा उद्योग | टोपी प्रकार: | सभी चिकित्सा विधानसभा उत्पादों की आवश्यकता है |
| शुद्धता: | उच्च | गारंटी: | 1 वर्ष |
| नियंत्रण: | स्वीकृति | संचालक: | एक ही या द्वि |
| प्रमुखता देना: | Servo Mechanism IV Bag Spike Ports Assembly Machine,8000-15000pcs/hr Injection Ports Assembly Machine,99% Qualified Rate Medical Product Assembly Machine |
||
Features
1. Used for automatic assembly for spike ports and injection ports of non-PVC double tube soft bag, aluminum-plastic PC infusion ports, PP and polypropylene dosing plugs.
2. All materials of the equipment are made of stainless steel + aluminum alloy, in compliance with ISO and GMP pharmaceutical packaging requirements.
3. Material for aluminum plastic cap sealing is made of titanium alloy, surface mirror polished to ensure smooth and nice sealing quality.
4. Rotation of sealing knife is driven by gear, each cap is sealed separately, achieving high qualified rate.
5. Each workstation is equipped with detection to make sure correctness and accuracy of assembling.
6. Main power comes from servo motor +indexing drive, which ensure high precision assembly.
7. PLC control system, touch screen HMI operation.
Properties
|
Applicable products |
Aluminum-plastic caps&ports PC ports, spike ports and injection ports for non PVC soft tube IV bag |
|
Production speed |
8000-15000pcs/hr (according to customer’s requirement) |
|
Rate of qualified product |
Above 99% |
|
Rate of operation rate |
Above 95% |
|
Power source |
AC380V,50Hz,4kw/hr |
|
Dimension |
L3500×W3400×H1800(mm) Actual size varied with different production speed |
|
Weight |
About 3000kg |
|
Operator |
1set/person |
