उत्पाद विवरण:
भुगतान & नौवहन नियमों:
|
| योग्य दर: | 98% | उत्पाद प्रमाणन: | सीई, आईएसओ |
|---|---|---|---|
| स्वचालन स्तर: | पूरी तरह से स्वचालित | मुख्य शक्ति: | सर्वो+सिलेंडर |
| उत्पाद का प्रकार: | असेंबली मशीन | विधानसभा पद्धति: | स्वत: भोजन और विधानसभा |
| वारंटी अवधि: | 1 वर्ष | वोल्टेज: | 220V |
| फ़ायदा: | दोनों आकार एक साथ इकट्ठा किया जा सकता है | केबल आकार: | तीन-चरण पांच-तार प्रणाली |
| क्षमता: | उच्च | डिटेक्शन सिस्टम: | फोटोइलेक्ट्रिक सेंसर |
| सक्रिय बल: | एक प्रकार का काम | ||
| प्रमुखता देना: | fully automated lotion pump machine 220V,lotion pump assembly machine 1500-2500pcs/hr,daily necessities assembly machine with warranty |
||
Features
1. Linear sliding rail conveying system will be applied and driven by servo motor to make intermittent movement, fixtures will be in a static state during assembly with precise positioning devices. Each workstation is equipped with a secondary positioning to improve qualified rate of product.
2. Manipulators of each station are independent, simple and easy for daily maintenance.
3. Manipulators are powered by cylinders, shorter time for spare parts change, simpler for debugging and maintenance.
4. The tube insertion process will be silicone oiled automatically, oil storage is 4L.
5. Enclosure for feeding plate can be equipped to reduce noise during production.
6. Each assembly process is followed by detection to ensure there will be no defective products in qualified products.
7. Whole equipment controlled by PLC system and touch screen operation.
Properties
|
Applicable products |
lotion pump shampoo pump water sprayer trigger sprayer perfume pump spray nozzle |
|
Production speed |
1500-2500pcs/hr (according to customer’s requirement) |
|
Rate of qualified product |
Above 98% |
|
Rate of operation rate |
Above 95% |
|
Power source |
AC380V, 50Hz, 4kw/hr |
|
Dimension |
Actual size varied with different production speed |
|
Weight |
About 3000kg |
|
Operator |
1set/person |
