उत्पाद विवरण:
भुगतान & नौवहन नियमों:
|
| प्रमाणपत्र: | सीई, आईएसओ 13485 | प्रचालन दर: | 96% |
|---|---|---|---|
| सुरक्षा विशेषता: | सुई उपयोग के बाद स्वचालित रूप से पीछे हट जाती है | उत्पादन प्रक्रिया: | स्वतः संयोजन |
| प्रसंस्करण प्रकार: | स्वत: | सक्रिय बल: | एक प्रकार का काम |
| संरक्षा विशेषताएं: | सुरक्षा लॉक, आपातकालीन स्टॉप बटन | नियंत्रण: | स्वीकृति |
| मुख्य शक्ति: | एक प्रकार का काम | स्वचालन ग्रेड: | स्वत: |
| शुद्धता: | उच्च | लागू उत्पाद: | खून की सुई |
| प्रचालन इंटरफ़ेस: | टच स्क्रीन | ||
| प्रमुखता देना: | automatic safety lancet production line,safety lancet production line with warranty,high efficiency safety lancet production line |
||
Features
1. For picking placement and injection molding of products with needles like blood lancet, blood collecting needles.
2. Equipped with two needle hoppers, storage capacity 200,000 needles, available 24 hours’ production.
3. Assemble at an inclined angle to avoid needle tip damaging.
4. Binding and tightening device installed in needle hoppers to avoid chaos of needles.
5. Easy removed hopper lid, needles can be loaded within 3 minutes.
6. Production cycle 10-15s, high productivity and good stability.
7. New needle adsorption system (patented), not vacuumization mode, low electricity consumption.
8. Customized according to customer’s real capacity and requirements.
Properties
|
Applicable products |
Pick and place needles then injection moulding for peripheral blood lancet, venous blood collecting needles, products with needles and injection moulding |
|
Production speed |
Depend on moulding cavity quantity |
|
Rate of qualified product |
Above 99% |
|
Rate of operation rate |
Above 97% |
|
Power source |
AC380V, 50Hz,4kw/hr |
|
Dimension |
L1950×W1250×H1900(mm) Actual size varied |
|
Weight |
About 2800kg |
|
Operator |
1set/person |
